? Verify
Note : This step is necessary. The chip must pass Verification before the
programming can be implemented. Some chips provide only the
accumulation check function, such as VerifyCRC instead of a
unit ‐ to ‐ unit check function. Very few chips do not provide the
accumulation check function.
? Security or Protect if encryption is required
Note : You may need to set the configuration word before performing
encryption. Refer to Device Configuration Word on page 37 for more
information.
Select Auto to finish all the operations in one step.
Execute Production Mode to Program Chips in Batches
Select Production Mode from the Option menu to program devices in large
quantities. This function facilitates the job of the user who programs chips in
batches.
In order to program chips in batches, the programmer always conducts the
insertion test.
The programmer waits for the chip insertion. The system displays the following
prompt: Please, insert a device into the socket . Refer to Insertion Test on page
82 for detailed information on chip insertion error messages.
Once you have properly inserted the chip, the auto batch ‐ processing
command starts automatically.
The programmer waits for the chip removal. When chip programming is complete,
the system displays the following prompt: Please, remove the device from the
socket .
Review the Operation Information window to check the programming result.
Refer to Operation Information Window on page 59 for more information.
To end production mode, select Cancel on the right side of the status bar.
Security and Password Input
To pre vent the user’s data from being used by another, the program asks the user
to input the password in the operation process.
The Set Password screen is illustrated below.
Superpro ? 5000 User’s Guide
70
